1.100% hydraulic driven.
2.hitting energy can be controlled by PLC.
3.U frame, X shape tup, excellent forging precision.
4.you can set all the forging parameter on touch screen, easy to operate.
5.hitting energy 25 KJ, 1 ton drop hammer.
6.this hammer can save 70%-90% energy than vapor-air hammer, low operating cost.
7.this hammer can work with forging robot, high automatic level.
Specifications:
TYPE: C92K-25
Hitting energy: 25 KJ
Weight of falling parts: 1700 KG
Max hit number per minute: 113
Hitting stroke: 470-685mm
Working oil pressure: 20 MPA
Main motor power: 75 KW
Machine eight: 41000KG
