1.100% hydraulic driven.
2.hitting energy can be controlled by PLC.
3.U frame, X shape tup, excellent forging precision.
4.you can set all the forging parameter on touch screen, easy to operate.
5.hitting energy 31.5 KJ, 1.5 ton drop hammer.
6.this hammer can save 70%-90% energy than vapor-air hammer, low operating cost.
7.this hammer can work with forging robot, high automatic level.
Specifications:
TYPE: C92K-16
Hitting energy: 31.5 KJ
Weight of falling parts: 2150 KG
Max hit number per minute: 100
Hitting stroke: 490-755mm
Working oil pressure: 20 MPA
Main motor power: 75 KW
Machine eight: 46000KG
