1.100% hydraulic driven.
2.hitting energy can be controlled by PLC.
3.U frame, X shape tup, excellent forging precision.
4.you can set all the forging parameter on touch screen, easy to operate.
5.hitting energy 100 KJ, 4 ton drop hammer.
6.this hammer can save 70%-90% energy than vapor-air hammer, low operating cost.
7.this hammer can work with forging robot, high automatic level.
Specifications:
TYPE: C92K-100
Hitting energy: 100 KJ
Weight of falling parts: 6800 KG
Max hit number per minute: 81
Hitting stroke: 595-885mm
Working oil pressure: 20 MPA
Main motor power: 2*75 KW
Machine eight: 141000KG
