1.low price
2.with 1 year guarantee, CE certificated products.
3.short delivery time.
4.Ready operation: economic and convenient
5.Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions—idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired
6.A special oil-pump is provided for lubricating the cylinders. Prior to running, turn the hand-crank of the pump to get the cylinders being lubricated beforehand.
Specifications:
Model: C41-1000
Weight of falling parts: 1000KG
Maximum hit energy:27 KJ
Hit number(min-1): 95
Heigh of working area: 800MM
Tup axis to frame front: 770MM
Dimension of top die surface(L x W):365x180MM
Dimension of bottom die surface(L x W): 365x180MM
Forged Square: 290x290MM
Forged round: Φ320MM
Motor Type: Y315S-6-B3
Motor Power: 75 KW
Hammer weight: 20000KG
Anvil block Weight: 13000KG
