1.low price
2.with 1 year guarantee, CE certificated products.
3.short delivery time.
4.Ready operation: economic and convenient
5.Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions—idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired
6.A special oil-pump is provided for lubricating the cylinders. Prior to running, turn the hand-crank of the pump to get the cylinders being lubricated beforehand.
Specifications:
Model: C41-560
Weight of falling parts: 560KG
Maximum hit energy:13.7 KJ
Hit number(min-1): 115
Heigh of working area: 600MM
Tup axis to frame front: 550MM
Dimension of top die surface(L x W):300x140MM
Dimension of bottom die surface(L x W): 300x140MM
Forged Square: 270x270MM
Forged round: Φ280MM
Motor Type: Y280S-6-B3
Motor Power: 45 KW
Hammer weight: 9800KG
Anvil block Weight: 6720KG
