1.low price, famous in blacksmithing/art forging.
2.with 1 year guarantee, CE certificated products.
3.short delivery time.
4.Ready operation: economic and convenient
5.Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions—idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired
6.A special oil-pump is provided for lubricating the cylinders. Prior to running, turn the hand-crank of the pump to get the cylinders being lubricated beforehand.
Specifications:
Model: C41-40
Weight of falling parts: 40KG
Maximum hit energy:0.53 KJ
Hit number(min-1): 245
Heigh of working area: 230MM
Tup axis to frame front: 235MM
Dimension of top die surface(L x W):116x53MM
Dimension of bottom die surface(L x W): 116x53MM
Forged Square: 52x52MM
Forged round: Φ68MM
Motor Type: Y132MI-6
Motor Power: 4 KW
Hammer weight: 860KG
