ANYANG FORGING PRESS MACHINERY I, C92K-16, FORGING, HAMMERS
  • Condition:New
  • Category:HAMMERS
  • Type:FORGING
  • Manufacturer:ANYANG FORGING PRESS MACHINERY I
  • Model:C92K-16
  • YOM:-
  • Location:China, Anyang
  • Price:On request
  • Stock No:-
  • Control:Manual
  • ID:AS37
Description:
1.low price, famous in blacksmithing/art forging.
2.with 1 year guarantee, CE certificated products.
3.short delivery time.
4.Ready operation: economic and convenient
5.Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions—idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired
6.A special oil-pump is provided for lubricating the cylinders. Prior to running, turn the hand-crank of the pump to get the cylinders being lubricated beforehand.
Specifications:
Model: C41-15
Weight of falling parts: 15KG
Maximum hit energy:0.16 KJ
Hit number(min-1): 245
Heigh of working area: 160MM
Tup axis to frame front: 140MM
Dimension of top die surface(L x W):70x40MM
Dimension of bottom die surface(L x W): 70x40MM
Forged Square: 30x30MM
Forged round: Φ35MM
Motor Type: Y100L-4
Motor Power: 2.2 KW
Hammer weight: 290KG
Dimensions:
850x500x980
Weight:
290KG
