Retrofiited in 2008 in UK.Disassembled now. Ready for shipping.
According to the documentation, the hammer was restored to the UK strictly according to the manufacturer's standards. Hydraulic control system is included. A set of new original guides made of special hard steel from Beche is included.
A complete set of technical documentation is available with a hammer. Including a drawing of the foundation, which will facilitate installation in a new location.
BÊCHÉ counterblow hammers are predominantly used for manufacturing large and ultra-large forgings. The high impact energy and tonnage of the hammer dies, moving in opposite directions, permits precision forming of large forgings. Counterblow hammers with hydraulic drives are particularly well suited to the medium tonnage range.
Specifications:
Energy of blow 25000 kgs
Stroke 1200 mm
Distance between slides 1070 mm
Ram width 1050 mm
Ram length 1500 mm
Weight 252 ton
Air Consumption Per Full Blow 4.5 Cubic Mtr
Compressor Size Cold Air 32.5 Cubic Mtr
Compressor Size Heated Air 220ºC 20.0 Cubic Mtr
Volume of Air Receiver 25.5 Cubic Mtr
