Punch Capacity: 50 Ton
Punch Hole Size: 13/16″ in 3/4″ Material Max
Punch Max Hole Size: 5″ in 1/8″ Material
Plate Shear Length of Blade: 15-1/2″
Angle Shear Capacity: 4″ x 4″ x 1/2″ & 5″ x 5″ x 3/8″
Bar Shear Rounds: 1/4″ to 1-1/2″
Bar Shear Squares: 1/2″ to 1″
Coper-Notcher Capacity: 50 Tons
Coper-Notcher Max. Cut: 2-3/4″ x 4″ x 1/4″
Punch End Strokes Per Min: 60 @ 1/2″
Throat Depth: 8″
Open Height: 13-1/2″
Stroke: 4-1/4″
Main Motor: 10 HP, 230/460v(Wired 460V), 3Ph
Equipped With:
Press Brake Bending Attachment, Channel Die Block Attachment, Oversized Punch Attachment, Several Punches & Dies, Foot Pedal
