SASS, N/A, MECHANICAL, JIG BORERS
  • Condition:Used
  • Category:JIG BORERS
  • Type:MECHANICAL
  • Manufacturer:SASS
  • Model:N/A
  • YOM:-
  • Location:India, Delhi
  • Price:On request
  • Stock No:-
  • Control:NC
  • ID:AS25074
Description:
Vertical Jig Boring Machine - SASS
Specifications:
Make - SASS (Italy)
Spindle Diameter - 85 mm
Table Size - 1000 mm x 1000 mm
Distance between Columns - 1700 mm
X Travel - 1000 mm
Y Travel - 1000 mm
Z Travel - 1000 mm
Spindle Feed - 370 mm
RPM - 32 to 1485 rpm
Drilling cut feed - 0.09 mm to 1.5 mm
Weight - 7.5 Tons (approx)
- complete NEW electricals with all components of L&T
- machine is in excellent condition , all functions can be tested under power.
- Electric Manuals available with machine.

The panel has been designed for automatic working of X-Axis (Table) & Y-Axis DC motors. The machine can even automatically drill holes of required depth along any axis.

This machine can work as a Plano Miller, Drilling Machine, Boring Machine & Grinding machine.
