Table surface: 900x1400mm
Max table load 2000 kg
Max. Strokes
-Longitudinal (x): 1120mm
-Cross (y): 710mm
Spindle stroke (z): 315mm
Traverse stroke 630 mm
Distance between column 1080 mm
Max distance between table and spindle nose 900 mm
Rapid Traverse 1000 mm/min
Spindle speed range: 0.36-2240 rpm
Max boring diameter 250 mm
Max boring diameter into St 60 32 mm
Max diameter of milling cutter 160 mm
Connected Load 8 kW
Dimensions (LxlxH) 3500x2700x3200 mm
Weight of machine: 10000kg
Year manufactured 1985
The machine is equipped with displays axis -new
