POWER 7,9 CV / 5,8 kW / 400 V
REFRIGIRATION PUMP POWER 100 W
MAX. DISTANCE ENTRE CENTRES 1.500 mm
Ø max.swing over bed 465 mm
Spindle speeds 25 - 2.000 r.p.m.
Nº of speeds 12
Main spindle morse taper MT 6
Support (nose) of main spindle Camlock DIN ISO 702-2 Nr. 6
Morse taper of tailstock sleeve MT 4
Dimensions (l x an x al) 2.750 x 1.245 x 1.568 mm
Net Weight 1.810 kg
