height of centers: 230 mm
center distance: 1000 mm
max. circulation-Ø over bed: ueber Bett 260 mm
spindle boring: 82 mm
spindle retainer: Camlock, Gr. 8
retainer taper tailstock: 4 MK
spindle speed: 37 - 1500 rpm
forwarding feed: laengs/plan 0,068 - 0,86 mm/U
thread pitch: 0,5 - 7 mm
electrical connection: 380 V, 5,5 kW
space needed: 2300 x 1070 x 1260 mm
weight: 2100 kg
