height of centers: 260 mm
center distance: 1625 mm
max. circulation-Ø over bed: ueber Bett 530 mm
spindle boring: 80 mm
spindle retainer: Gr. 8
retainer taper tailstock: 5 MK
spindle speed: 45 - 1600 rpm
forwarding feed: laengs/plan 0,05-1,5 / 1/2 mm/U
thread pitch: 0,5 - 15 mm
electrical connection: 380 V, 9 kW
space needed: 2850 x 1070 x 1400 mm
weight: 1700 kg
