Swing over bed 280 mm
Distance between centers 600/750 mm
Hole through spindle 25 mm
Spindle taper MT4
Tailstock taper MT2
Spindle speed (6 steps) 125—2000 rpm
Compound travel 80 mm
Cross slide travel 155 mm
Range of thread Metric version 0.25 - 2 .5 mm (14 threads pitches)
Imperial version 12 - 96 TPI (9 threads pitches)
Motor output power 750 W
Overall dimension (LxWxH) Model 600 1260x630x470 mm
Model 750 1410x630x470 mm
Weight (Net/Gross) Model 600 170/220 kg
Model 750 175/230 kg
Packing size (LxWxH) Model 600 1370x740x650 mm
Model 750 1520x740x650 mm
