Max swing over bed 400 mm
Max swing over cross slide 220 mm
Distance between centers 1000 mm
Taper of spindle bore 55 mm
Range of spindle speed (24)12,5-1600 U/min
Working feeds 0,025 - 2,8 mm/U
Rapid travel 3800 /1900 mm/min
Taper of tailstock spindle MK 5
Motor power 10 kW
Weight 3 t
Dimensions,LxWxH ca. 2,8 x 1.2 x 1,5 m
