Max swing over bed 630 mm
Max swing over cross slide 350 mm
Distance between centers 3000 mm
Taper of spindle bore 70 mm
Range of spindle speed 10-1250 U/min
Working feeds 0,04-1,6 mm/U
Rapid travel 3800 /1900 mm/min
Taper of tailstock spindle MK 5
Motor power 13 kW
Weight 5000 kg
Dimensions,LxWxH ca. 4950x1740x1350mm
