Centroid T400 control with 15” LCD
5HP Spindle Motor, D1-4, 1-9/16” through hole spindle
Max 4,000 rpm spindle speed
Hardened & Ground way
C5 Double nut precision ball screws hardened & ground for high accuracy and long lasting
FC30 Meehanite Casting main frame with annealed & stress relieved for long term reliability
100% Laser tested for positioning accuracy & repeatability
Rugged cast iron design to provide maximum rigidity & stability
Tool box & Tools
Full enclosure with electrically interlocked
Coolant System
Central lubrication system
Built-in Quartz work light
