MAX TURNING DIAMETER ......................... 74"
MAX SWING .................................... 80"
FACEPLATE DIAMETER ........................... 30"
SPINDLE RPM .................................. 0-250 RPM
SPINDLE HORSE POWER .......................... 60 HP
SPINDLE GEAR RANGES .......................... 2
LIVE SPINDLE RPM ............................. 0-4500 RPM
LIVE SPINDLE HORSE POWER ..................... 15 HP
LIVE SPINDLE GEAR RANGE ...................... 2
TOOL CHANGERS (ATC) .......................... 10 Positions
TOOLS - SANDVIK CAPTO ........................ C6 60mm
POSITIONING:
Head 1 X Axis ................................ 40"
Head 1 Z Axis ................................ 30"
Head 2 X Axis ................................ 40"
Head 2 Z Axis ................................ 30"
ACCURACY - ALL AXES FULL TRAVEL .............. .0005"
REPEATABILITY - ALL AXES ..................... +/- .0002"
AXIS RAPIDS .................................. 400"/ MIN
AXIS FEED RATES .............................. 0-400" / MIN
MACHINE WEIGHT ............................... 30,000 LBS
MACHINE DIMENSIONS ........................... L 170" x W 144" x H 109"
FEATURES:
FANUC ........................................ 18ITA-2 - 4 AXIS CNC
CHIP CONVEYOR
HIGH PRESSURE COOLANT THRU TOOLING
TOTAL ENCLOSURE - SLIDING DOOR FOR EASY ACCESS
CONSTRUCTION:
BASE: STURDY SINGLE STRUCTURE POLYMERGRANITE, WEIGHT 22,000 LBS
ENCLOSURE: REINFORCED STEEL METAL
WAY COVERS: STAINLESS STEEL
