Max swing over bed: Φ310mm
Max swing: Φ130mm
Xaxis: 220mm
Zaxis: 450mm
Max bardiameter: Φ40mm
No. of spinolle speeds: 200-2500r/m
The principal axis hand move to clip tightly or the spirit
move to clip tightly: 200-2500r/m
Tool post station: four side or six side knife rest
Repeation positioning accuracy:<=0.003mm
Max-feed speed Xaxis: 3000mm
Max-feed speed Zaxis: 6000mm
Power of main motor: 2 2/3kw
Overall dimensions(LxWxH):1550X900X1380mm
Net Weight: 1000kg
