Max swing over bed: Φ400mm
Max swing: Φ200mm
Xaxis: 220mm
Zaxis: 800mm
workholding method: hand chuck
Max bardiameter: Φ52mm
No. of spinolle speeds: 200-3000r/m
Bore awl degree inside the pricipal axis:Mt6#
Tool post station: 4 or 6 station turret(selective pairing)
Repeation positioning accuracy:<=0.003mm
Max-feed speed Xaxis: 3000mm
Max-feed speed Zaxis: 6000mm
tailstock sleeve diameter: Φ55mm
Mohs center taper: No.4mt
maximum traverse of tailstock sleeve: 120mm
Power of main motor: 5.5kw
Overall dimensions(LxWxH):2260X1250X1770mm
Net Weight: 1500kg
