Max. manu. dia. Ø32 Ø36
Spindle speed range 6000 rpm
X-axis travel (vertical) 190
Y-axis travel (longitudinal) 490
Z-axis travel (cross) 165
Max. bar feeding dia. Ø32 Ø36
Collet of spindle TRB-32 TRB-36
Rapid trav. speed (X, Y, Z axis) 30 m/min
Min. input unit 0.001
No. of external turning tools 6(5)
O.D. turning tool size 12x12x120 (Option 16x16x120)
No. of internal turning tools 5
I.D turning tool size ER20
No. of cross side driving tools 4
No. of front side driving tools 3
Cross & front side of driving tool ER20
Rev. speed of driving tools 0-4000 rpm Stepless speed
Spindle motor 7.0kw
X, Y, Z-axis servo motor X axis:1. 5 kw
Y,Z axis: 1.0 kw
Coolant pump 3/4 HP
Auto lubricator capacity 3-6cc / 15 min
Radial live tooling servo motor 1.5 kw
Axial live tooling servo motor 0.75 kw
Total power consumption 7.5 kw
Center height 965
Machine size (LxWxH) 1611x1858 x1919
N.W. 2800 kgs
