turning diameter 400 mm
turning length 1000 mm
control Fagor 8055 TC
bed width 300 mm
spindle taper A2-6
spindle bore 52 mm
transmission ratio 2
tailstock quill diameter 63 mm
tailstock quill stroke 130 mm
max. length of work piece 1000 mm
max. swing over slide 200 mm
x-travel 225 mm
z travel 870 mm
rapid traverse x/z 4/5 m/min
max. length of work piece 1000 mm
max. swing over slide 200 mm
x-travel 225 mm
z travel 870 mm
chuck size 200 mm
taper of spindle bore -M6
frequency conversion motor power 5.5 kW
rapid traverse x/z 4/5 m/min
repeatability of toolpost 0.008 mm
vertical 4-position toolpost changing time 2.4 s
horizontal 6-position toolpost changing time 3.0 s
taper of tailstock quill M4 MK
turning speeds 20-650/75-2500 U/min
power requirement 5,5 kW
weight of the machine ca. 1950 kg
dimensions of the machine ca. 2300/1480/1520 mm
ACCESSORIES:
electric handwheel 2 Stk.
cooling system
working lamp
chuck guard
tools
door lock
coolant system
swivellable control
electric 4 position coolant-through tool post
chip bin, removable
Paint colour: Ash grey/dark grey (RAL 7012) gloss
3-jaw chuck diameter 200 mm
