main features:
-high speed
-high spindle torque
-big spindle bore
-automatic forced lubrication
-hardened and ground guideways
-brand-new design eterior
-CE certificate of TÜV Rheinland, Germany & ISO 9001 CQC, China
WARRANTY: 12 months on parts
PAYMENT: 100% before loading
turning diameter 560 mm
turning length 2000 mm
control Fanuc Oi-TC MGI
turning diameter over bed 560 mm
bed width 400 mm
spindle taper D8
spindle bore 82 mm
spindle speed: 7-2200 mm
transmission ratio 3-stufig
tailstock quill diameter 75 mm
tailstock quill stroke 150 mm
max. length of work piece 2000 mm
max. swing over slide 330 mm
x-travel 305 mm
z travel 1430 mm
chuck size 250 mm
taper of spindle bore 1:20
rapid traverse x/z 6/10 m/min
repeatability of toolpost 0.008 mm
vertical 4-position toolpost changing time 2.4 s
horizontal 6-position toolpost changing time 3.0 s
taper of tailstock quill 5 MK
power requirement 7,5 kW
weight of the machine ca. 2750 kg
dimensions of the machine ca. 3330x1750x1620 mm
accessories:
swivellable control
3-jaw chuck dia. 250 mm
coolant system
door lock
tools
chuck guard
working lamp
cooling system
electric handwheel 2 Stk.
electric 4 position coolant-through tool post
CNC control Fanuc 0i-TC with Manual guide I
Paint colour: Ash grey/dark grey (RAL 7012) gloss
