turning diameter 520 mm
turning length 1000 mm
control Fanuc Oi-TC MGI
turning diameter over bed 520 mm
chuck size 250 mm
spindle taper ISO A 2-8
spindle speed: 35-3500 U/min
x-travel 260 mm
z travel 1100 mm
tailstock quill diameter 100 mm
tailstock quill stroke 139 mm
taper of tailstock quill 5 MK
turning diameter over bed slide 310
guideway box type
rapid speed x-axis 12 m/min
tool size 25*25 mm
tool size 12 mm
rapid speed x-axis 12 m/min
dia. spindle bore 87 mm
max. dia over bed 500 mm
max. bar dia 74 mm
power requirement 18.5(22) kW
weight of the machine ca. 7800 kg
dimensions of the machine ca. 4834x1830x1977 mm
