turning diameter 680 mm
turning length 1000 mm
control Fanuc Oi-TC MGI
turning diameter over bed 600 mm
chuck size 300 mm
spindle taper ISO A 2-8
spindle speed: 35-3000 U/min
x-travel 325 mm
z travel 1110 mm
tailstock quill diameter 140 mm
tailstock quill stroke 150 mm
taper of tailstock quill 5 MK
turning diameter over bed slide 310 mm
guideway linear type
rapid speed x-axis 24 m/min
tool size 25*25 mm
tool size 12 mm
rapid speed x-axis 12 m/min
dia. spindle bore 88 mm
max. dia over bed 500 mm
max. bar dia 74 mm
power requirement 18.5(22) kW
weight of the machine ca. 8500 kg
dimensions of the machine ca. 5084x2082x2050 mm
