Gantry Robot Loader, Remote Manual Pulse Generator, Chip Conveyor, Tool Presetter, Chucker (No Tailstock)

Chuck Size 6"
Max Diameter Bar Capacity 1.77"
Max Swing Over Bed / Carriage 20" / 11.4"
Max Turning Diameter 12.6" / 6.7"
Max Machining Length 12.7"
Spindle Motor 15 HP AC
Spindle Speed 60 - 6000 RPM
Spindle Bore 2.09"
Spindle Nose A2-5
Spindle Torque 70.4 ft. lbs.
Tools 12
Rapid Traverse Rates (X / Z) 1181 / 1417 IPM
X-Axis Travel 6.9"
Z-Axis Travel 12.9"
Turret Index (Single Step) 0.15 Seconds
Machine Weight 6393 lbs.


FEATURES:
FANUC 21iT CNC CONTROL
12.1" Color TFT
Gantry Robot Loader
Remote Manual Pulse Generator
Chip Conveyor
Tool Presetter
Chucker (No Tailstock)

6393
