CNC, Manual and Teach Modes, G-Code and Conversational Programming, Aloris Quick-Change Single Tool Post, 6" Manual 3-Jaw Chuck, Tailstock, Electronic / Manual Handwheels, Full Enclosure
Specifications:
Chuck Size 6"
Max Diameter Bar Capacity 1.75"
Max Swing Over Bed / Carriage 18.5" / 9.44"
Max Turning Diameter 9.44"
Distance Between Centers 29.5"
Bed Width 11.81"
Tools 4
Spindle Speed 20 - 4000 RPM
Spindle Bore 1.8"
Spindle Nose D1-5
Spindle Motor 10 HP
Rapid Traverse Rates (X & Z) 315 IPM
X-Axis Travel 9.4"
Z-Axis Travel 29.52"
Tailstock Taper MT#3
Machine Weight 2420 lbs.
FEATURES:
MITSUBISHI CNC CONTROL
CNC, Manual and Teach Modes
G-Code and Conversational Programming
Aloris Quick-Change Single Tool Post
6" Manual 3-Jaw Chuck
Tailstock
Electronic / Manual Handwheels
Full Enclosure
