Four Spindles & Two Turrets, C-Axis Milling Capability on All Four Spindles, (4) 5C Collet Chucks on All Four Spindles, FMB Doppel Turbo 3800 Dual 12 ft. Magazine Barfeeds, Mayfran Chip Conveyor, Auto Parts Catcher for Upper & Lower Spindles
Specifications:
Chuck Size 6"
Max Diameter Bar Capacity 1.1"
Max Swing Over Bed 6.3"
Max Turning Diameter 3.94"
Max Machining Length 16.10"
Main Motor 15 HP
Tools 12 x 2 (4 Live)
Spindle Speed 0 - 5000 RPM
Spindle Bore 0.98"
Rapid Traverse Rates (X / Z) 472 / 787 IPM
X-Axis Travel (Upper & Lower) 3.07"
Z-Axis Travel (Upper / Lower) 7.5" / 9.5"
C-Axis Index 3 Degrees
Milling Motor 2.2 HP
Milling Speed 5000 RPM
Turret Index 0.4 Seconds
Machine Dimensions (L x W x H) 86" x 54" x 70"
Machine Weight 5720 lbs.
FEATURES:
SIEMENS 810T CNC CONTROL
9" Monochrome CRT
Four Spindles & Two Turrets
C-Axis Milling Capability on All Four Spindles
(4) 5C Collet Chucks on All Four Spindles
FMB Doppel Turbo 3800 Dual 12 ft. Magazine Barfeeds
Mayfran Chip Conveyor
Auto Parts Catcher for Upper & Lower Spindles
Three Color Tower Light
