Controller FANUC 0i-TC
Swing Over Bed mm Ø700
Swing Over Cover mm Ø600
Max Cutting Diameter mm Ø560
Spindle
Spindle Nose ASA A2-8
Wheel Dia in 13"~20"
Spindle Bearing Dia mm Ø130
Spindle Hole Diameter mm Ø86
Spindle Speed rpm 2500
Spindle Motor (Cont./ 30min.) KW /HP α30i (30\37 KW)=(40\50HP)
Max Spindle Torque Kgf-m 38.4
Z-Axis Travel mm 640
X-Axis Travel mm 335(290+45)
Rapid Traverse X/Z-Axis M/min 20/20
Servo Motor (X/Z) KW 3.0/3.0
Index Type Hydraulic
Number of Tools units 10
Tool Shank mm 25×25
Boring Bar Size mm Ø50
Tool Chang Time (T-T) sec 0.2
180 Tool Chang Time (Non T-T) sec 0.7
Coolant Pump Kw/HP 1.1/1.5
Chip Flush Pump Kw/HP 0.86/1.1
Coolant Tank Volume L 340
Dimensions (L×W×H) M 3.53x1.9x2.0
Net Weight kg 6000
