Swing Over Bed mm 400
Swing Over Cover mm 235
Max Cutting Diameter mm 220
Cutting Diameter mm 200
Max. Cutting Length mm 171
Max. Bar Material Diameter in/mm Ø42
Spindle
Spindle Nose ASA A2-5
Power Chuck Size in/mm 6"
Spindle Bearing Diameter mm 80
Spindle Hole Diameter mm 56
Spindle Speed rpm 6000
Spindle Motor (Cont./ 30min.) KW 3.7 / 5.5 ß3-10000i
Spindle Runout mm 0.003
Z-Axis Travel mm 200
X-Axis Travel mm 130
Rapid Traverse- Z-Axis M/min 24
Rapid Traverse- X-Axis M/min 24
Index Type Hydraulic
Number of Tools units 8
Tool Shank mm 20×20
Boring Bar Size mm 32
Tailstock (Option)
Tailstock Travel mm (130)
Quill Travel mm (75)
Quill Diameter mm (60)
Quill Taper Hole MT (MT-3)
Quill Activation Hydraulic
Tailstock Positioning Manual
Dimensions (L×W×H) M 1.66x1.55x1.72
Net Weight kg 2000
