Chuck Size 15"
Max Diameter Bar Capacity 4.5"
Max Swing Over Bed / Carriage 33.16" / 21.1"
Max Turning Diameter 21"
Distance Between Centers 59"
Max Machining Length 32"
Tools 8 + 8
Spindle Speed 3150 RPM
Spindle Bore 5.28"
Spindle Nose A2-11
Spindle Motor 56 HP AC
Rapid Traverse Rates 700 IPM
X-Axis Travel (Upper & Lower Turrets) 12.28"
Z-Axis Travel (Upper & Lower Turrets) 59"
Machine Dimensions (L x W x H) 230" x 137" x 91"
Machine Weight 23,750 lbs.
FEATURES:
GIDDINGS & LEWIS NUMERIPATH 8000 CNC CONTROL
2 MB Memory
3.5" Floppy Disc Drive
15" Hydraulic Chuck
Chucker (No Tailstock)
Jorgenson Chip Conveyor (Right Side Exit)
Yellow Operating Condition Light
