C, Y & B-Axis Milling Capability, Twin Opposed Spindles with Upper Tool Spindle & Lower Turret, (12) Position Lower Turret with Milling Capability, (2) 16" Schunk NCD 400-165 Hydraulic Quick-Change 3-Jaw Chucks, 40 Tool Magazine (HSK-A63), (3) Extended Boring Bar Tool Magazine, Marposs In-Process Work Measuring System, Broken Tool Detection, Coolant Thru Upper Tool Spindle (1160 psi), Programmable Steady Rest (SLV2), Tool Presetter (ECO 210), Four Color Tower Light

Chuck Size 16" (2)
Max Diameter Bar Capacity (L & R) 4.01"
Max Swing Over Bed / Carriage 24.01"
Max Turning Diameter 15.35"
Distance Between Spindles 72"
Spindle Speed (L & R) 20 - 3200 RPM
Spindle Motor (L & R) 92.5 / 60.3 HP
Spindle Torque (L & R) 678.55 ft. lbs.
Tools 40
Milling Motor (Upper Tool Spindle) 20.1 / 13.4 HP
Milling Speed (Upper Tool Spindle) 12,000 RPM
Rapid Traverse Rates (X / Z / Y) 1771 / 2756 / 945 IPM
Max Tool Diameter 3.34" / 5.31"
Max Tool Length 13.77"
Max Tool Weight 26.46 lbs.
Milling Motor (Lower Turret) 13.4 HP
Milling Speed (Lower Turret) 12.5 - 4000 RPM
X-Axis Travel 23.81"
Z-Axis Travel 73.62"
Y-Axis Travel +/- 4.13"
B-Axis Travel +/- 120 Degrees
X-Axis Travel (Lower Turret) 8.93"
Z-Axis Travel (Lower Turret) 72.44"
Machine Dimensions (L x W x H) 353" x 162" x 125"
Machine Weight 44,100 lbs.


FEATURES:
SIEMENS 840D POWERLINE CNC CONTROL
15" Color TFT
C, Y & B-Axis Milling Capability
Twin Opposed Spindles with Upper Tool Spindle & Lower Turret
(12) Position Lower Turret with Milling Capability
(2) 16" Schunk NCD 400-165 Hydraulic Quick-Change 3-Jaw Chucks
(3) Extended Boring Bar Tool Magazine
40 Tool Magazine (HSK-A63)
Marposs In-Process Work Measuring System
Broken Tool Detection
Coolant Thru Upper Tool Spindle (1160 psi)
Programmable Steady Rest (SLV2)
Tool Presetter (ECO 210)
Four Color Tower Light

353 x 162 x 125

44100
