Description:
Upper Tool Spindle with Lower Turret and Identical Opposed Spindles, C-Axis Milling Capability on Both Spindles, Y-Axis Milling Capability on Upper Tool Spindle, 60 Tool Magazine (HSK-63A Holders), 12.8" SMW Autoblock Hyd. Chuck on Main Spindle, 12.4" SMW Hyd. Chuck on Sub Spindle, Parts Exit Conveyor, Tailstock Capability, Scale Feedback System for Upper Z-Axis, Breuning Short Magazine Barfeed, High Pressure Coolant System, Chip Conveyor, Coolant System, Marposs In Process Measuring Device, Automatic Front Doors, Turret Steady Rest, MCIS-DNC Software, Four Color Tower Light
Specifications:
# Axis: 5
Chuck Size: 12 "
Bar Capacity: 3.54 "
Power: 60 hp
Max RPM: 4000 rpm
Turning Dia: 25.19 "
Swing: 25.19 "
Machining Length: 75.98 "
Tailstock (Yes/No): No
Dimensions: 340" x 140" x 120"
Weight: 54,000
Control: Siemens 840D
Weight:
24000 kg
