ISO 9001 certified
Ease-of-use FANUC oi-mate CNC control
CNC programmable spindle speeds from 45 to 2,500 rpm
Large spindle bore 2-1/16”, D1-6
Full enclosure safety front and rear guards
One-piece solid cast iron machine base
Heavy Duty guideway width 11 13/16”
Electrical automatic 4-way turret toolpost
MPG Metal handwheel for X & Z
Fully ballscrews enclosure
RS 232 interface
High speed machining
Popular Ease-of-use Conversational programming, Conversational leads you to go through programming your part, just fill in the blanks and check the graphic. Select from all canned cycles, such as, profiling, material removing, roughing and finishing, inside & outside threading, line, arc, drilling and floating tapping, cut-off, grooving, radius, chamfering
G code and M code programming
CSS-constant surface speeds
CAD/CAM connector
Tools library
Tool length & radius compensation
Spindle is balanced, hardened and precision ground
Spindle is supported at 3-point by high precision bearings
All gears and shafts are hardened and precision ground
Guideways induction hardened and precision ground
Automatic lubrication system for ballscrews and guideways
Automatic lubrication system in headstock and feed box
One year industrial warranty for parts
