Specifications:
Swing Diameter: 20"
Chuck Size: 8" 3 Jaw
Max Cutting Diameter: 10"
Between Center: 20"
Spindle Speeds: RPM 50-4000
Number of Tools 10
Spindle Motor HP: 20 Vector Drive
Voltage: 230 VAC, 3 Ph
Equipped With:,(*must be verified by buyer):
HAAS 32-BIT CNC CONTROL WITH 10" CRT SCREEN
RS-232C PORT INTERFACE FOR DNC OPERATION
LTP20 Tool Presetter System
PTS20 Fully Programmable Hydraulic Tailstock
HPC Parts Catcher
HIL High Intensity Lighting
LCC Chip Auger
BFI Barfeed Interface With Haas ServoBar 300 Barfeeder
Standard 3.5" Floppy Disc Drive
Standard 1 Meg Memory
Standard Rigid Tapping
Standard 8” Kitagawa 3-Jaw Power Chuck
All Available Manuals
APPROX. DIMENSIONS: 127" x 75" x 74"
MACHINE WEIGHT (APPROX): 9000 LBS
Hours Subject to Change:
Servo on 6,983 hours
In motion 3,080 hours
Spindle 3,414 hours
