3.5" Floppy Disc Drive, 1 MB Memory, 10" Hydraulic 3-Jaw Chuck, Fully Programmable Hydraulic Tailstock, Tool Presetter, Green Work Indicator Light, High Intensity Lighting, Bolt-On Type Turret
Specifications:
Chuck Size
10"
Max Diameter Bar Capacity
3"
Max Swing Over Bed / Carriage
30" / 14.5"
Max Turning Diameter
17"
Distance Between Centers
39"
Max Machining Length
32"
Spindle Motor
30 HP
Spindle Speed
20 - 3400 RPM
Spindle Bore
3.5"
Spindle Nose
A2-6
Spindle Torque
300 ft. lbs.
Tools
12
Rapid Traverse Rates (X & Z)
710 IPM
X-Axis Travel
11.3"
Z-Axis Travel
34"
Tailstock Taper
MT#4
Machine Dimensions (L x W x H)
162" x 77" x 74"
Machine Weight
16,000 lbs.
FEATURES:
HAAS CNC CONTROL
12" Color LCD
3.5" Floppy Disc Drive
1 MB Memory
10" Hydraulic 3-Jaw Chuck
Fully Programmable Hydraulic Tailstock
Tool Presetter
Green Work Indicator Light
High Intensity Lighting
Bolt-On Type Turret
