Chuck Size 6"
Max Diameter Bar Capacity 1.63"
Max Swing Over Bed 21"
Max Turning Diameter 8.25"
Max Machining Length 14"
Spindle Motor 10 / 7.5 HP
Spindle Speed 50 - 5000 RPM
Spindle Bore 2"
Spindle Nose A2-5
Tools 12
Rapid Traverse Rates (X / Z) 400 / 630 IPM
X-Axis Travel 7.75"
Z-Axis Travel 14"
Tool Index Time (Step) 0.5 Seconds
Machine Dimensions (L x W x H) 85.4" x 66.7" x 69.4"
Machine Weight 6000 lbs.
FEATURES:
GE FANUC 21-TB CNC CONTROL
9" Monochrome CRT
16C Collet Capability
Chucker (No Tailstock)
