Conversational & G-Code Programming, Self-Contained Pneumatic Collet Chuck, Integral Spindle Motor, Q Setter (Tool Presetter), One Touch Programmable Tailstock, X & Z Axis Torque Limiter Protection, Mayfran Chip Conveyor, Spindle Liners
Specifications:
Chuck Size 10"
Max Diameter Bar Capacity 2.5"
Max Swing Over Bed 15"
Max Turning Diameter 10"
Max Machining Length 23.6"
Spindle Motor 20 HP
Spindle Speed 20 - 3600 RPM
Spindle Bore 3.1"
Spindle Nose A2-8
Tools 10
Rapid Traverse Rates 1181 IPM
X-Axis Travel 8.2"
Z-Axis Travel 24.8"
Turret Index (Single Step) 0.1 Seconds
Tailstock Taper MT #5
Machine Weight 10,000 lbs.
FEATURES:
SEICOS L MULTI CNC CONTROL
Serial Number NR30777
14" Color CRT
Conversational & G-Code Programming
Self-Contained Pneumatic Collet Chuck
Integral Spindle Motor
Q Setter (Tool Presetter)
One Touch Programmable Tailstock
X & Z Axis Torque Limiter Protection
Mayfran Chip Conveyor
Auto Parts Catcher
Spindle Liners
