C-Axis Milling Capability, CNC Enhancements Autobar 400 Short Magazine Barfeed, Auto Parts Catcher, Programmable Tailstock Body & Quill, Servo Drive Turret, No Chuck Included, Chip Conveyor (Side Exit), Two Gear Range Headstock, Slant Bed Box Way Construction, Three Color Tower Light
Specifications:
Chuck Size 12"
Max Diameter Bar Capacity 3"
Max Swing Over Bed / Carriage 22.8" / 17.7"
Max Machining Diameter 17.7"
Distance Between Centers 28"
Spindle Motor 25 / 20 HP
Spindle Speed 3500 RPM
Spindle Bore 3.42"
Spindle Nose A2-8
Tools 12
Milling Speed 3000 RPM
Milling Motor 5 HP
Rapid Traverse Rate (X / Z) 787 / 944 IPM
X-Axis Travel 11.4"
Z-Axis Travel 25.6"
C-Axis Index .001 Degrees
Turret Index (Single Step) 0.2 Seconds
Tailstock Taper MT #5
Machine Dimensions (L x W x H) 177" x 83" x 89"
Machine Weight 15,400 lbs.
FEATURES:
FANUC 0i-TB CNC CONTROL
Serial Number TEN3009
8.4" Color CRT
C-Axis Milling Capability
CNC Enhancements Autobar 400 Short Magazine Barfeed
Auto Parts Catcher
Servo Driven Turret
Programmable Tailstock Body & Quill
Three Color Tower Light
Chip Conveyor (Side Exit)
No Chuck Included
Two Gear Range Headstock
Slant Bed Box Way Construction
Manufacture Date November 2003
