- Turning diameter: 1200: mm - turning length: 3000 mm - turning diameter over bed slide: 760 mm - spindle diameter in front. Stock: 330 mm - Spindle bore: 205 mm - spindle head: A15 DIN 55026 - Speed ​​range II: 50 - 1000: U / min - spindle motor: 100 kW - Torque: 7908 Nm - cross slide ways: 720 / 3050 mm - feed force along: 20 kN - thrust crosswise: 12 kN - Rapid - plan along /: 10 m / min - quill diameter: 200 mm - Quill stroke: 200 mm - Workpiece weight max. - Flying: 2250 kg - weight of workpiece between centers max. 5,000 kg - Total power consumption: 135 kW - Machine Weight: 32 tons - about space: 5.9 x 2.4 x 3.4 m [...Technical data truncated]

-
