21" Hydraulic 3-Jaw Non-Thru Hole Chuck, Manual Tailstock, Joegenson Chip Conveyor (Right Rear Exit), Multi-Tap Transformer, Four Gear Range Headstock, Hardened & Ground Double "V" Ways

Chuck Size 21"
Max Swing Over Bed / Carriage 34" / 21.65"
Max Turning Diameter 34"
Distance Between Centers 63.78"
Spindle Motor 60 / 40 HP
Spindle Nose A1-11
Spindle Bore 4.64"
Spindle Speed 2 - 1200 RPM
Spindle Torque 5310 ft. lbs.
Tools 8 (OD) + 4 (ID)
Rapid Traverse Rates (X / Z) 236 / 315 IPM
X-Axis Travel 25.79"
Z-Axis Travel 63.78"
Machine Dimensions (L x W) 168.5" x 171.2"
Machine Weight 19,030 lb.


FEATURES:
MAZATROL T-32-2 CNC CONTROL
Serial Number 102809
14" Color CRT
21" Hydraulic 3-Jaw Non-Thru Hole Chuck
Manual Tailstock
Jorgenson Chip Conveyor (Right Rear Exit)
Multi-Tap Transformer
Four Gear Range Headstock
Hardened & Ground Double "V" Ways

168 x 171

19030
