8" Hydraulic Chuck, Programmable Tool Eye, Programmable Tailstock Body & Quill, Auto Parts Catcher, Jorgenson Chip Conveyor (Side Exit)

Chuck Size 8"
Max Diameter Bar Capacity 2"
Max Swing Over Bed 17.32"
Max Turning Diameter 11.81"
Max Machining Length 17.5"
Spindle Motor 20 / 15 HP
Spindle Speed 5000 RPM
Spindle Bore 2.44"
Spindle Nose A2-6
Tools 8
Rapid Traverse Rates (X / Z) 1200 / 1300 IPM
X-Axis Travel 7.125"
Z-Axis Travel 20.125"
Turret Index (Single Step / Full) 0.35 / 0.72 Seconds
Tailstock Taper MT #4
Machine Dimensions (L x W x H) 105" x 68.5" x 73.1"
Machine Weight 9370 lbs.

FEATURES:
MAZATROL T-PLUS CNC CONTROL
12" Monochrome CRT
Conversational Programming
Graphic Display
8" Hydraulic Chuck
Programmable Tool Eye
Programmable Tailstock Body & Quill
Auto Parts Catcher
Jorgenson Chip Conveyor (Side Exit)

105 x 68 x 73

9370
