Chuck Size 5"
Max Diameter Bar Capacity 1.26"
Max Swing Over Bed / Carriage 18.5" / 9.5"
Max Turning Diameter 3.7"
Max Machining Length 2.36"
Spindle Motor 7.5 / 5 HP
Spindle Speed 35 - 7000 RPM
Spindle Bore 1.73"
Spindle Nose 115 mm Flat
Tools Gang
Rapid Traverse Rates (X & Z) 787 IPM
X-Axis Travel 11.8"
Z-Axis Travel 9.45"
Machine Dimensions (L x W x H) 96" x 70" x 62"
Machine Weight 3300 lbs.
FEATURES:
MAZATROL EIA CNC CONTROL
9" Monochrome CRT
EIA/ISO Input Function
Graphic Display
Collet Chuck
Chucker (No Tailstock)
Manual Tool Eye
