Chuck Size 6"
Max Diameter Bar Capacity 1.57"
Max Swing Over Bed 11.81"
Max Turning Diameter 6.3"
Max Machining Length 11.91"
Spindle Motor 10 / 7.5 HP AC
Spindle Speed 45 - 4500 RPM
Spindle Bore 1.97"
Spindle Nose A2-5
Tools 8
Rapid Traverse Rates 945 IPM
X-Axis Travel 3.75"
Z-Axis Travel 11.42"
Turret Index (Single Step / Full) 0.2 / 0.5 Seconds
Tailstock Taper MT #4
Machine Dimensions (L x W x H) 66.5" x 47.6" x 69.1"
Machine Weight 5730 lbs.
FEATURES:
MAZATROL T-2 CNC CONTROL
14" Color CRT
Conversational Programming
Graphic Display
6" Hydraulic Chuck
Manual Tailstock
Programmable Tool Eye
