PC/MCIA Interface, 1 MB Memory, 3.5" Floppy Disc Drive, ATS 16C Collet Chuck, LNS Servo S2 Short Magazine Barfeed, Auto Parts Catcher, Servo Drive Tailstock, Servo Driven Turret, Programmable Tool Eye, Yellow Operation Light, Multi-Tap Transformer, Chip Conveyor (Rear Exit)

Chuck Size 6"
Max Diameter Bar Capacity 2"
Max Swing Over Bed / Carriage 21.6" / 11"
Max Turning Diameter 11"
Max Machining Length 12.1"
Spindle Motor 15 / 10 HP AC
Spindle Speed 5000 RPM
Spindle Bore 2.4"
Spindle Nose A2-5
Tools 12
Rapid Traverse Rates (X / Z) 1181 / 1299 IPM
X-Axis Travel 7.5"
Z-Axis Travel 13"
Turret Index (Single Step) 0.18 Seconds
Tailstock Taper MT #4
Machine Dimensions (L x W x H) 72" x 64.2" x 67"
Machine Weight 7270 lbs.


FEATURES:
MAZATROL FUSION 640T NEXUS CNC CONTROL
10.4" Color LCD
Graphic Display
Conversational Programming
PC/MCIA Interface
1 MB Memory
3.5" Floppy Disc Drive
ATS 16C Collet Chuck
LNS Servo S2 Short Magazine Barfeed
Auto Parts Catcher
Servo Driven Tailstock
Servo Driven Turret
Programmable Tool Eye
Yellow Operation Light
Multi-Tap Transformer
Chip Conveyor (Rear Exit)

72 x 64 x 67

7270
