Chuck Size 8"
Max Diameter Bar Capacity 2"
Max Swing Over Bed / Carriage 20.9" / 15.74"
Max Turning Diameter 11.75"
Max Machining Length 20.78"
Spindle Motor 25 / 20 HP AC
Spindle Speed 35 - 5000 RPM
Spindle Bore 2.4"
Spindle Nose A2-6
Tools 12
Rapid Traverse Rates 1180 IPM
X-Axis Travel 7.12"
Z-Axis Travel 22.75"
C-Axis Index .001 Degrees
Turret Index (Single Step / Full) 1.3 / 5 Seconds
Tailstock Taper MT#4
Machine Dimensions (L x W x H) 115.6" x 62.2" x 74.8"
Machine Weight 9700 lbs.
FEATURES:
MAZATROL T-32-3 CNC CONTROL
14" Color CRT
Graphic Display
Conversational Programming
8" Hydraulic Chuck
Programmable Tool Eye
Programmable Tailstock Body & Quill
Chip Conveyor
