C-Axis Milling Capability, Programmable Sub Spindle with 5 Degree Index, 10" Hydraulic Chuck on Main Spindle, 6" Hydraulic Chuck on Sub Spindle, Programmable Tool Eye, Auto Parts Catcher, Chip Conveyor (Side Exit)
Specifications:
Chuck Size 10"
Max Diameter Bar Capacity 2.5"
Max Swing Over Bed / Carriage 20.90" / 16.54"
Max Turning Diameter 11.75"
Distance Between Spindles 34.25"
Max Cutting Length 20.47"
Spindle Motor 25 / 20 HP AC
Spindle Speed 35 - 4000 RPM
Spindle Bore 2.99"
Spindle Nose A2-6
Tools 12 (Live or Turning)
Milling Motor 5 HP AC
Milling Speed 120 - 3000 RPM
Sub Spindle Chuck Size 6"
Sub Spindle Motor 10 HP AC
Sub Spindle Index 5 Degrees
Rapid Traverse Rates 1180 IPM
X-Axis Travel 7.125"
Z-Axis Travel 22.75"
Machine Dimensions (L x W x H) 124.4" x 63.4" x 80.3"
Machine Weight 11,135 lbs.
FEATURES:
MAZATROL T-32-3 CNC CONTROL
14" Color CRT
Conversational Programming
Graphic Display
C-Axis Milling Capability
Programmable Sub Spindle with 5 Degree Index
10" Hydraulic Chuck on Main Spindle
6" Hydraulic Chuck on Sub Spindle
Programmable Tool Eye
Auto Parts Catcher
Chip Conveyor (Side Exit)
