ATS Collet Chuck, Auto Parts Catcher, Parts Exit Conveyor, Chip Conveyor, (6) Position Tailstock Turret, Cut Off Confirmation, Barfeed Interface, Three Color Tower Light
Specifications:
Chuck Size 6"
Max Diameter Bar Capacity 1.65"
Max Turning Diameter 2.95"
Max Machining Length 8.66"
Spindle Speed 170 - 5000 RPM
Spindle Bore 2"
Spindle Nose A2-6
Spindle Motor 15 / 10 HP
Tools 12 + 6 (Tailstock)
Rapid Traverse Rates 472 IPM
X-Axis Travel 3.93"
Z-Axis Travel 7.28"
Turret Index (Single Step) 0.2 Seconds
Machine Dimensions (L x W x H) 116.9 x 59" x 68.5"
Machine Weight 8300 lbs.
FEATURES:
FANUC 21-T CNC CONTROL
Serial Number BD60155T
9" Monochrome CRT
ATS - 110MM - 16C Collet Chuck
Auto Parts Catcher
Parts Exit Conveyor
Chip Conveyor (Side Exit)
(6) Position Tailstock Turret
Cut Off Confirmation
Barfeed Interface
Three Color Tower Light
