12" Hydraulic 3-Jaw Chuck, Turbo Chip Conveyor (Side Exit), Chucker (No Tailstock), Tool Presetter (Removable), Heavy Duty Box Way Construction
Specifications:
Chuck Size 12"
Max Diameter Bar Capacity 3.5"
Max Swing Over Bed / Carriage 20.5" / 16.1"
Max Turning Diameter 17.7"
Max Turning Length 18.5"
Spindle Motor 20 / 15 HP
Spindle Speed 28 - 2800 RPM
Spindle Bore 4.1"
Spindle Nose A2-8
Spindle Torque 451 ft. lbs.
Tools 10
Rapid Traverse Rates (X / Z) 590 / 787 IPM
X-Axis Travel 10.2"
Z-Axis Travel 19.7"
Turret Index (Single Step) 0.5 Seconds
Machine Dimensions (L x W x H) 78.7" x 68.3" x 63.1"
Machine Weight 8800 lbs.
FEATURES:
MORIC MSC-521 (FANUC 21T) CNC CONTROL
Serial Number 1244
9" Monochrome CRT
12" MMK ZA8-12-93 Hydraulic 3-Jaw Chuck
Turbo Chip Conveyor (Side Exit)
Chucker (No Tailstock)
Tool Presetter (Removable)
(3) Boring Bar Holders
(2) OD Wedge Blocks
Heavy Duty Box Way Construction
